HCPL-4502-320E
Part NoHCPL-4502-320E
ManufacturerBroadcom Limited
DescriptionOPTOISOLTR 3.75KV TRANS 8-DIP GW
Datasheet
Download Now!
ECAD Module
Specification
Series-
PackageTube
Product StatusActive
Number of Channels1
Voltage - Isolation3750Vrms
Current Transfer Ratio (Min)19% @ 16mA
Current Transfer Ratio (Max)50% @ 16mA
Turn On / Turn Off Time (Typ)200ns, 600ns
Rise / Fall Time (Typ)-
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)20V
Current - Output / Channel8mA
Voltage - Forward (Vf) (Typ)1.5V
Current - DC Forward (If) (Max)25 mA
Vce Saturation (Max)-
Grade-
Qualification-
Operating Temperature-55°C ~ 100°C
Mounting TypeSurface Mount
Package / Case8-SMD, Gull Wing
Supplier Device Package8-DIP Gull Wing
In Stock:
2613
available for immediate sale in a store
available for immediate sale in a store
Pricing
| QTY | UNIT PRICE | EXT PRICE |
|---|---|---|
| 1 | 0.9832 | |
| 10 | 0.9636 | |
| 100 | 0.9341 | |
| 1000 | 0.9046 | |
| 10000 | 0.8652 |
