ACPL-217-50CE
RoHS

ACPL-217-50CE

Part NoACPL-217-50CE
ManufacturerBroadcom
DescriptionOPTOISOLATOR 3.75KV TRANS 4SOIC
Datasheet Download Now!
ECAD Module ACPL-217-50CE
Get Quotation Now!
Specification
Series-
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Product StatusActive
Number of Channels1
Voltage - Isolation3750Vrms
Current Transfer Ratio (Min)200% @ 5mA
Current Transfer Ratio (Max)400% @ 5mA
Turn On / Turn Off Time (Typ)3µs, 3µs
Rise / Fall Time (Typ)2µs, 3µs
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)80V
Current - Output / Channel50mA
Voltage - Forward (Vf) (Typ)1.2V
Current - DC Forward (If) (Max)50 mA
Vce Saturation (Max)400mV
Grade-
Qualification-
Operating Temperature-55°C ~ 110°C
Mounting TypeSurface Mount
Package / Case4-SOIC (0.173", 4.40mm Width)
Supplier Device Package4-SO
In Stock: 14546
Pricing
QTY UNIT PRICE EXT PRICE
1 0.805
10 0.7889
100 0.7648
1000 0.7406
10000 0.7084
Shipping Information
Shiped FromShenZhen Warehourse
Lead TimeCall right now
